AutomaticCeiling Fire Extinguisher 12Kg.CONICAL HOOP OF BIG DIAMETER (160mm) FOR EASIER INSTALLATION

In closedrooms, the quantity of the extinguishing agent needed is 12Kg for an area of about 10m² and height of 1,5-2m from the extinguishing point. In openareas, the demanded quantity of the extinguishing-agent must be increased due to losses.

Capacity 12Kg

Extinguishing Agent ABC 40%

Operating Temperature -30 to +60 °C

Max Allowable Pressure 18 bar

Test Pressure 26 bar

Volume of Equipment 14Lt lt

Cylinder Height 271 ± 2 mm

Cylinder Diameter 302 ± 1,5 mm

Cylinder Neck Thread M30 x 1.5

Valve Material CuZn40Pb2

Cylinder Material DC01 (St12)

Safety Valve 21-26 bar

Approx. gross Weight 16 kg

Approx. Dimensions 460x340 mm

Paint Finish RAL 3000
